Henger Yokohama Type Pneumatic Rubber Fender for Boat Protection with BV Standard Certification

محصولات

دوشاخه لوله لاستیکی فشار بالا

با ما تماس بگیرید

86-157-6394-0460

اکنون تماس بگیرید

Henger Yokohama Type Pneumatic Rubber Fender for Boat Protection with BV Standard Certification

مقدار تولیدی:	1
قیمت:	380
بسته بندی استاندارد:	0.51M-4.812m
دوره تحویل:	5-8 سال
روش پرداخت:	L/C ، D/A ، D/P ، T/T ، Western Union ، MoneyGram
ظرفیت تامین:	5-8 سال

جزئیات اطلاعات

توضیحات محصول

اطلاعات دقیق

محل منبع

شاندونگ ، چین

نام تجاری

Henger

گواهی

BV, DNV, RL, CCS, ABS, GL, LG

شماره مدل

پیستون

توضیحات محصول

Henger Pneumatic Rubber Fender with BV Certification for Durable and Safe Marine Docking Protection

Qingdao Henger Shipping Supplies Co., Ltd is a high-tech enterprise specializing in marine products manufacturing, including marine rubber fenders, marine airbags, navigation marks, and marine buoys. Located in Qingdao, our products are ISO 9001-2008 certified and hold IACS quality authentication from CCS, BV, GL, ABS, and LG.

Inflatable Rubber Fender Introduction

The "Yokohama Type Inflatable Rubber Fender" was developed in 1958. These floating inflatable rubber fenders have evolved alongside ship technology to accommodate increasingly larger vessels like VLCCs, ULCCs, large gas carriers, bulk carriers, and floating structures.

Used worldwide for ship-to-ship (STS) transfer operations and ship-to-dock (STD) operations, these fenders play a critical role in safe ship berthing and mooring. Millions have been supplied globally since their creation.

Key Features:

Constructed with multiple layers of strong tire-cord for pressure and cutting resistance
Design safety factor based on accepted theory and extensive experimentation
Large-size fenders include safety valves for accidental over-pressure protection
Provides completely uniform surface pressure on contact
Particularly suitable for LNG-ship terminals due to low, uniform surface pressure
Special manufacturing techniques and raw material formula enhance kneading-resistance
Each layer treated with specially formulated mucilage for dust removal and enhanced adhesion

Technical Specifications

Fender Size	Compression Amount (60%)	Noumenon Weight (Kg)	Weight with Protective Jacket (Kg)
D (mm) * L (mm)	Reaction (KN)	Energy Absorption (KNm)
500 * 1000	64	6	23
600 * 1000	74	8	28
700 * 1000	137	17	58
1000 * 1500	182	32	82
1000 * 2000	257	45	148
1200 * 2000	297	63	167
1350 * 2500	427	102	220
1500 * 2500	499	134	270
1500 * 3000	579	153	318
1700 * 3000	639	191	380
2000 * 3500	875	308	580
2000 * 4000	1000	352	680
2500 * 4000	1381	663	1064
2500 * 5500	2019	1131	1268
3000 * 5000	2422	1357	1980
3000 * 6000	2906	1293	2400
3300 * 4500	1884	1175	2380

Frequently Asked Questions

"I have ships but don't know how to choose the size of Factory Price Rubber Inflatable Floating Pontoon for Ship Launching Made in China?"

Don't worry. We have more than 20 years' experience. Please provide your ship information, and we can suggest suitable sizes for you.

"What's your MOQ?"

Our minimum order quantity is 1 piece.

"What's your warranty period?"

Our warranty period is 2 years. We will repair or replace products if quality issues are confirmed to be our responsibility.

برچسب ها:

گلگیرهای دریایی بادی,

جزئیات محصولات

محصولات

پنوماتیک فندر لاستیکی

فندر لاستیکی دریایی

فندر زیردریایی

پنوماتیک دریایی فندر

فوم پر شده فندر

ایربگ لاستیکی دریایی

کشتی پرتاب هواپیما

توربین بادی دریایی

دریای تعمیرات هواپیما

شناور اسلحه فولادی

شناور دریایی

شناورهای دریایی

سد ایمنی غلتک

طناب مورینگ دریایی

لنگرهای قایق دریایی

زنجیر لنگر دریایی

مارین مورینگ بولارد

دوشاخه لوله لاستیکی فشار بالا

Henger Yokohama Type Pneumatic Rubber Fender for Boat Protection with BV Standard Certification

مقدار تولیدی:	1
قیمت:	380
بسته بندی استاندارد:	0.51M-4.812m
دوره تحویل:	5-8 سال
روش پرداخت:	L/C ، D/A ، D/P ، T/T ، Western Union ، MoneyGram
ظرفیت تامین:	5-8 سال

اطلاعات دقیق

توضیحات محصول

اطلاعات دقیق

محل منبع

شاندونگ ، چین

نام تجاری

Henger

گواهی

BV, DNV, RL, CCS, ABS, GL, LG

شماره مدل

پیستون

مقدار حداقل تعداد سفارش:

قیمت:

380

جزئیات بسته بندی:

0.5*1M-4.8*12m

زمان تحویل:

5-8 سال

شرایط پرداخت:

L/C ، D/A ، D/P ، T/T ، Western Union ، MoneyGram

قابلیت ارائه:

5-8 سال

توضیحات محصول

Henger Pneumatic Rubber Fender with BV Certification for Durable and Safe Marine Docking Protection

Inflatable Rubber Fender Introduction

Key Features:

Constructed with multiple layers of strong tire-cord for pressure and cutting resistance
Design safety factor based on accepted theory and extensive experimentation
Large-size fenders include safety valves for accidental over-pressure protection
Provides completely uniform surface pressure on contact
Particularly suitable for LNG-ship terminals due to low, uniform surface pressure
Special manufacturing techniques and raw material formula enhance kneading-resistance
Each layer treated with specially formulated mucilage for dust removal and enhanced adhesion

Technical Specifications

Fender Size	Compression Amount (60%)	Noumenon Weight (Kg)	Weight with Protective Jacket (Kg)
D (mm) * L (mm)	Reaction (KN)	Energy Absorption (KNm)
500 * 1000	64	6	23
600 * 1000	74	8	28
700 * 1000	137	17	58
1000 * 1500	182	32	82
1000 * 2000	257	45	148
1200 * 2000	297	63	167
1350 * 2500	427	102	220
1500 * 2500	499	134	270
1500 * 3000	579	153	318
1700 * 3000	639	191	380
2000 * 3500	875	308	580
2000 * 4000	1000	352	680
2500 * 4000	1381	663	1064
2500 * 5500	2019	1131	1268
3000 * 5000	2422	1357	1980
3000 * 6000	2906	1293	2400
3300 * 4500	1884	1175	2380

Frequently Asked Questions

"I have ships but don't know how to choose the size of Factory Price Rubber Inflatable Floating Pontoon for Ship Launching Made in China?"

Don't worry. We have more than 20 years' experience. Please provide your ship information, and we can suggest suitable sizes for you.

"What's your MOQ?"

Our minimum order quantity is 1 piece.

"What's your warranty period?"

Our warranty period is 2 years. We will repair or replace products if quality issues are confirmed to be our responsibility.
